DWDM

Product Features

l  Up to 25.78Gb/s data links

l  DWDM EML transmitter and PIN receiver

l  100 GHz ITU channel spacing with integrated wavelength locker

l  Up to 10km on 9/125um SMF

l  Hot-pluggable SFP28 footprint

l  Support Digital Diagnostic interface

l  Duplex LC/UPC type pluggable optical interface

l  RoHS-10 compliant and lead-free

l  With CDR function

l  Single +3.3V power supply

l  Compliant with SFF+MSA and SFF-8472

l  Metal enclosure, for lower EMI

l  Meet ESD requirements, resist 8KV direct contact voltage

l  Case operating temperature : 0°C to +70°C/ -40°C to +85°C


分享+
订购信息
产品型号传输速率
(Gb/s)
波长
(nm)
距离
(Km)
激光器发射光功率
(dBm)
接收器接收灵敏度
(dBm)
温度
(℃)
规格书
DWDM LR25 CH17-61 10 EML -1.0~4.0 PIN < -11.0 0~70
DWDM LR(15)25 CH17-61 15 EML 0~5.0 APD < -14.0 0~70
